There is a new release (version 5.08.01) available of our 3D program XFEM4U.
Click here to install the new release.
On release notes you will find an overview of all changes
The most important new features:
1. New Graphical dragging of supports
Beam Grids - Pile Optimization: In the side view of the concrete beam, it was already possible to change the pile distances by clicking on the dimension lines. This is of course still possible.
What is new is that it can now also be done graphically. You can now graphically "drag" the support. After changing this, the beam grid is automatically recalculated and you can see the result immediately.
2. New Colors smoothly or banded
The colors (in beams and plates) can now be displayed smoothly or banded. It is also possible to set the number of colors in the color scale.
3. Improved Menu options "Zoom extents" and "Zoom selection"
The menu now includes Zoom extents and Zoom Selection.
Zoom extents displays the entire construction with the default camera position. With Zoom selection the selection is displayed full screen. If nothing is selected, the entire structure is displayed with the last camera position.
Click here to install the new XFEM4U version (5.08.01) immediately.
In release notes you will find an overview of all changes.
